Additive Manufacturing for Defense: Targeting Qualification

Authored by: John E. Barnes, Robert Carter PhD (The Barnes Global Advisors), Jesse Geisbert (U.S. Navy), & Nick Fulgenzi (U.S. Army)

Defense and Why Do You Hear “Weapons Systems”?

The U.S. Marines are fond of saying, “Improvise, adapt, and overcome all obstacles in every situation.”  What does this mean and what does it have to do with Additive Manufacturing (AM)?  Weapons systems in their basic forms are just that, SYSTEMS.  They have evolved to be capable of interoperability with other weapons systems and other military services whether that be within a single defense organization or a coalition such as NATO (North Atlantic Treaty Organization).  Weapons systems are initially designed to meet an operational capability, i.e. deliver 12 troops to a destination 100 km away and land vertically.  After that, the weapons system needs to be capable of meeting the requirements developed over hundreds of years of experience because it can’t be known whether it will operate in a desert (heat & sand), the arctic (cold), near or in the ocean (wet and corrosive), so it must meet requirements that are established.  The weapons system will also have an intended lifetime; but we have all seen some of these platforms serve much longer than anticipated and are given extended life through upgrades and extensive maintenance.

When we think about AM in this instance, the manufacturing process must be repeatable and reliable to even be considered for manufacturing parts for a weapons system. We ultimately cannot conceive of all the scenarios it could be used in, so we must be able to verify that parts manufactured via AM ultimately can meet minimum thresholds – full stop.  When we qualify a part, we also qualify the process, the operator, and the facility.

In article 1 of this series, Kevin Slattery and John Barnes laid out the basic framework for qualification. Subsequently, in article 2, we examined the environment of space, followed by heavy transportation in article 3.  In each of these articles, spearheaded by the first, the authors elucidated that the process for qualification is essentially the same.  The testing and types of testing may vary based on the expected environment but in all instances, industry wants a repeatable, reliable process.

Why is Defense Manufacturing Different?

The loss of the USS Thresher on April 10, 1963, was a watershed moment in the history of submarine disasters. The Thresher was a nuclear-powered attack submarine, and its tragic sinking claimed the lives of all 129 crew members on board. The subsequent investigation revealed that a piping failure in the engine room led to a cascading series of events, ultimately causing the submarine to exceed its maximum depth, causing it to implode. This disaster prompted a comprehensive reevaluation of submarine safety and design. In response, the U.S. Navy implemented stringent technical requirements, rigorous testing protocols, and enhanced safety measures to prevent such catastrophic incidents in the future.  Contrary to the perception that stringent technical requirements might lead to slow, antiquated processes and timelines, the nuclear submarine community is actively engaged in ensuring that technical requirements are right-sized and forward-leaning.

The drive for strict technical requirements in submarine design and construction stems from a deep commitment to the safety of naval personnel and the protection of critical assets.  The loss of the Thresher highlighted the inherent risks associated with underwater operations, especially in the demanding conditions of deep-sea exploration and warfare. The cost of submarines, both in terms of financial investment and human lives, underscores the delicate balance between risk and reward. While submarines are invaluable assets for national security, their complexity and the harsh operating environment demand uncompromising technical standards to mitigate potential disasters. The stringent requirements and approval process imposed on submarine development aim to uphold the highest standards of safety and reliability, acknowledging the inherent risks of undersea operations while ensuring that the rewards of naval superiority are achieved without unnecessary sacrifice.

There is a saying that complex systems fail in complex ways as highlighted by the USS Thresher example.  Manufacturing for defense applications is surprisingly complicated by several factors that may not be apparent at first.  First, all of the weapons systems are complex, many of which get more complex as time marches on.  The Department of Defense (DoD) expects all material to function to specifications, at which time calculations can be made for each new mission requirement. The most challenging missions could involve the worst service conditions using platforms that are operating beyond their initial design life due to service life extensions.  While there are civilian equivalents of planes, ground vehicles, or ships, defense requirements will drive designs and materials selection to push manufacturing into new and challenging spaces.

Example:  The C-130

The original design specification for what became the C-130 was published in 1951.  Versions of C-130s are being produced still today, so this is a very good example of a system that is capable of many different missions.  The C-130’s primary mission is tactical airlift, meaning it must be capable of operating off austere airfields and airdropping troops into hostile areas.

Today, many variants of the C-130 use the same system (i.e. airplane) but adapt.  For example, the WC-130 is configured for weather operations, often referred to as hurricane hunters because they collect data on severe weather.  Other variants include:

AC-130 is a gunship, KC-130 brings an airborne refueling capability, EC-130 can broadcast TV and radio, HC-130 is operated by the Coast Guard and performs search and rescue, LC-130 has skis to operate in arctic conditions, and the MC-130 which supports Special Operations Forces.

Another aspect of defense manufacturing is the defense-specific requirements for service.  Pending if this is a C-130 transport, an M1 Abrams tank, or a Virginia-class submarine, there will be requirements for blast/shock and ballistic loads that have little crossover to civilian components.  Also, these platforms must survive the loads across a large range of service conditions from the high atmosphere for aircraft, the depths of the oceans for our submarines, or extreme hot and cold climates of any potential conflict zone.  This pushes the use of higher-performance materials which have challenging manufacturing considerations.

For the warfighter who operates the aircraft, ground vehicle, or submarine, in whatever variant, for whichever mission, their objective is - the mission.  There cannot be a concern as to whether the weapons system is up for the challenge because it is using AM.  The design authority ensures the performance of the system is maintained. The customer oversees this as the certifying entity that certifies that the platform is ready for service.

It Starts with the Part

When introducing a new manufacturing method and a new design (as these typically go hand in hand), the part must meet or exceed the requirements.  This could be met through analysis if there is sufficient data on the design/manufacturing method from other parts or other industries/applications.  When the process is newer and little data exists, the data will need to be generated and would follow the “building block” process, starting with coupons and work up to full-size testing if required.  This process is designed to build trust in the new component, design, or manufacturing process and it follows the System Engineering “V” (Figure 1) as shown in prior articles.

Figure 1. System Engineering “V”

Naturally, to build trust in the part, we also must ensure we have trust in the machinery, the operator, and the facility that those elements operate within.  As we noted in the first article, there is the TBGA AM Qualification Framework (Figure 2) to use as an illustration of where are in the process.

Figure 2. TBGA AM Qualification Framework

Failing is Inevitable

The question is how will it fail, and can we live with that?  As the second article in our series with NASA eloquently said, “Can we trust this system to perform without a doubt?” - defense systems are similar.  What are the consequences of failure of that part?  Detailed analyses are completed to answer these questions and it does matter whether the system operates in the air, underwater, or on the ground just as it matters whether loss of the part in question could result in loss of the system, or catastrophic failure.

For instance, if a non-critical component of the M1 Abrams tank has failed, the system is still mission-capable while the part is ordered. But if a mission-critical component fails, such as the engine, then the vehicle is non-mission capable, and readiness is negatively impacted. If such a part fails during combat, then it puts the mission and/or soldiers' lives in danger. Thus, the importance of both having supply chain availability of parts, especially mission-critical parts, and the inherent reliability of those parts ensured by design, manufacturing, and testing requirements.

But What About Improvising, Adapting, and Overcoming?

We’ve mostly discussed the ideal case where we design for that known condition, where we have some design flexibility to produce the part and installation into the system on the assembly line.  The fun begins once the system is fielded, and we need to sustain it.  Maintainers have a demanding role in finding spare parts, creating repairs, and generally adapting and overcoming wherever the system is and whatever logistical challenges they face.  These challenges can be unique to weapons systems.  Compared to any commercial world equivalent, the systems don’t see as much time in service and will be in service for generations of soldiers, sailors, marines, and airmen/women.

Sourcing spare parts is a challenge when the need (i.e. quantity) is low and the mix is high.  Traditional manufacturing has evolved over the decades and as legacy manufacturing methods get replaced with better, newer methods, the parts coming from those methods must be proven to meet or exceed the requirement.  The manufacturer of the part might have little insight into where the part is going, but the design authority and System Program Office (SPO) do.  They all must work together to ensure that the machinery produces a part that can seamlessly fit into the supply chain.  After all, the 3D printer only generates a shape.  It becomes a part later.

Adapt – We have to deal with the reality of the DIB

Developing the next generation of defense while sustaining the current force is demanding on the defense industrial base (DIB).  Increasing system service life (e.g. C-130 or M1 Abrams tank), the number of variants of a platform (over 70 variants of the C-130 and 20 of the Abrams), changing the performance requirements to meet new and evolving threats, and the increasing complexity for both the current platforms and those in development is necessitating a larger defense base, with increasing design and manufacturing flexibility.    Today, supply chains are stretched and the supply and demand situation seeks efficiency with high volumes of the same design.  Sadly, the pressures listed above drive to a high mixture of low volume quantity parts.  When this eventuates, lead times are excessively long, and prices go higher.  The DoD does not have the time or resources needed to requalify every part within the millions of parts in the defense inventory.  Efforts are needed to qualify the equivalence or interchangeability of AM parts to enable the DOD to accept AM production.

Overcome – The Lead Time is Excessive

One such example of this scenario are parts made of castings and numerous weapons systems being negatively impacted through long delivery times, which then negatively impact their mission ready capability.  Many entities, such as the Submarine Industrial Base (SIB) are assessing the viability of using AM to meet or exceed the requirements of the original parts.  Matt Sermon, Executive Director of Strategic Submarines Program Executive Office (PEO SSBN) recently said, “Eighty percent reduction in schedule for components that we need in shipyards, for components that we need in new construction, is not unrealistic”[1]. This is largely due to the loss of domestic manufacturing capability over the past several decades. From 1979 to 2017, the US lost 7.1 million manufacturing jobs – or 36% of the workforce[2], and there are 25% fewer manufacturing firms and plants than there were in 1997[3].  Unfortunately, defense production is dependent upon domestic manufacturing sources, and these changes to DIB are providing a new threat that we, as a nation, must overcome.  The DoD is investing in new infrastructure to regrow the traditional DIB while also expanding it through enabling and adopting new manufacturing technologies.  Additive manufacturing is needed to augment and broaden the industrial base to provide new means of production.

Improvise – Using AM in the Field

Not only can AM yield benefits to the DIB, but it has huge potential to provide new modalities of improvisation.  Over the past several years, the services have been introducing forward-deployed advanced manufacturing cells.  These cells are meant to address the challenge of manufacturing at the point of need versus waiting for critical supplies through long logistic tails.  There are examples of the Army replacing a part that would take 126 days for shipping that was made overnight.[4]  The Navy[5] and Marine Corps[6] have deployed metal AM systems.  Most recently, the DoD has deployed SPEE3D’s cold spray additive manufacturing systems to Ukraine[7].   These systems enable development of replacement parts, or rapid modification, to adapt or improvise to meet an unforeseen challenge.  While these technologies are new and not yet qualified to produce every part, not all parts are critical and do not require rigorous qualification and certification to be of value to the warfighter.  The risk of using AM parts must be balanced against the benefit of its use, so the Services are generating guidance on where AM parts are acceptable and what the qualification requirements are for various levels of criticality.

Trust Me, I Know What I’m Doing

As Ronald Reagan said, “Trust, but verify.” Our Qualification Framework works in much the same way.  Once proven to be acceptable, we then constantly verify the Defense Industrial Base (DIB) is manufacturing parts that go into systems and can meet the system performance supported by the data that was originally generated.

I Feel Another Quote Coming…

We are setting ourselves up with a Top Gun chestnut, “This is a target-rich environment” to choose some quotes to inspire our industry.  The challenges are many, but the question is whether the destination is worth the journey.  We say not only yes, but Let’s Go!!  From John F. Kennedy’s inspirational words as we entered the Space Race, he challenged the country to get to the moon in less than 9 years.  Suppose we can be so bold as to co-opt President Kennedy’s words for our scenario where our mission is to ensure that additive manufacturing is part of the manufacturing arsenal and where factories are clean and safe. In that case, the people want to be there, and we don’t need to make excuses for lack of commercial merit, data, etc.  This is a mission worth working for.  Kennedy went on to say that we choose to do these things, “not because they are easy, but because they are hard.” And when the journey is hard, most will not follow.

Let’s Get Moving

Thomas Edison noted this in his day, and it is still true today, “Opportunity is missed by most people because it is dressed in overalls and looks like work.” Our takeaway from the very moving second article was that the hard work pays off.  Understanding AM and how it works, what it can do, and where it opens design opportunities can pay off even in very demanding commercial situations, because it improves the system.  It isn’t about the printer ultimately.  The printer is an enabler sure, but if you want to get a part qualified, and in revenue service, attention is on the overall process. The printer just must work in a repeatable, reliable manner.

Investing in AM is worth it.  The key word here is investing.  A lot of what we see today is shortsighted and not looking at the long game.  Manufacturing is great for economies and an essential part of the Defense Industrial Base[8].  This isn’t lip service or hype – it is a major recommendation coming from the DoD in response to Executive Order 14017. Investing in manufacturing is investing in your country - your allies - your way of life.  It is also an investment in your neighbors, whether they work in a factory, or support one as an accountant, marketer, or medical professional because manufacturing dollars stay regional.

Investing in defense is money well spent.  After all, it is called defense, not offense.  The goal is deterrence.  U.S. Army General Mark Milley said, “The only thing more expensive than deterrence is actually fighting a war, and the only thing more expensive than fighting a war is fighting one and losing one.”

As we have noted in the series of articles, the process of qualification is unchanged by any advanced manufacturing method, but the testing and types of testing will impact how much data is required to obtain qualification.  In this article, we’ve highlighted why defense requires the testing and data to be qualified.  AM is one of several forms of advanced manufacturing and the trend in advanced manufacturing is complexity and integration – it’s a system of systems.  Complexity requires a team and an ecosystem.  Ecosystems are inherently strong because they are businesses that rely on each other, but they also rely on each business to invest and optimize.  It is the very epitome of the USMC mantra, “Adapt. Improvise. Overcome.”

The Qualification Framework Article Series can also be found on Additive Manufacturing Media.

 …

Author’s Note: Nick Fulgenzi is a civilian employee of U.S. Army and is not affiliated with Barnes Global Advisors.
