The Additive Manufacturing Process: How Much Data is Enough?
This article is the second in a series on AM process verification, read the first article here.
Tensile bars, tensile bars and more tensile bars. If you are a current or aspiring aerospace AM part producer, you must be asking, “How many more tensile bars do I have to pull?” If you are bringing to market a new AM material, a new AM process or perhaps both, then chances are you have been building a ton of these simple “dog bones.”
You have been gathering data internally to improve your material and/or process and for your initial data sheet. Once you have gone to market and started attracting potential customers to your material and/or process, one of the first things your potential customer asks for is MORE mechanical property coupons. They seem to not be too interested in all the data you have already collected. They want more, sometimes, lots more. You would not be the first to ask, “How much data is enough?”
The Seventh-Inning Stretch
It’s only a bit of a stretch to relate this to the great sport of baseball — call it a seventh-inning stretch. Baseball is simple, yet complex, much like additive manufacturing. In its simplicity, a baseball team wins an individual game by scoring more runs than the opposing team. So, the question is, “How many runs do you need to win a baseball game?” The answer is simply, one more than the opposing team. Relating back to AM, the simple answer to the data question is that you need just one more data point than your customer’s engineering group wants.
But here is where the simplicity stops and the complexity begins. The number of runs needed to win a game is based on many variables; macro variables include available players, weather, opponent and even the ballpark, and micro variables narrow down to the specifics of a single pitch. Similarly, there are many variables in AM processing that affect the mechanical properties — both macro variables, such as the printing process, the material or the type of machine, and micro variables such as the material batch, the particular machine or the cleanliness of energy. So, we can determine that the amount of data needed is based on an understanding of the variables, chief among these are the customer and the application of the AM parts.
Playing by the Rules
Another parallel between scoring runs in baseball and collecting data in AM is the requirement to play by the rules. To score a run in baseball, the rules require the player to physically touch each base in a particular order. Similarly, the data for AM must follow the rules, a proven process done in a particular order. In the first article of this series, “The Additive Manufacturing Process: An Expectation of Consistency,” we addressed the importance of having a sound material and process specification prior to generating the mechanical data; the specifications should be addressing the micro variables of both the material and process and demonstrating the stability and repeatability of the technology.
A recent article from my colleagues at The Barnes Global Advisors, Kevin Slattery, D.Sc. and Jennifer Coyne, titled “Order of Operations in Metal Additive Manufacturing,” documents the necessary order of operations in AM production, a handy tool anyone can use to determine if a solid process is being followed. There are many ways to generate data, but if the provider is not following the rules, then the data becomes suspect and we start from scratch.
Show Me the Stats
Another parallel to baseball is in the capability of AM to generate statistics. Even though runs cannot be used from one baseball game to another, the statistics of the run generation can be very valuable to help determine strategies and player lineups for future games, not to mention future salaries.
Within AM, the same can hold true. When working with a new customer or application, the provider may have data to share, but in most cases, new data will also be requested. It is not to say the preceding data is useless. It will provide guidance, but the new customer or new application may require a whole new set of environmental conditions or engineering requirements that need to be tested. Or, there may be a new set of specifications, in which case all new data is required, unless there can be some agreement to bridge testing. But all this data can be statistically utilized for allowables, or creating mechanical property values that have a certain level of confidence to which the engineer can design. In the next article, we will elaborate on the confidence of AM produced hardware and whether getting to aircraft certification is possible.
The Closer
A famous quote from the movie Bull Durham stated,
“This is a very simple game. You throw the ball, you catch the ball, you hit the ball. Sometimes you win, sometimes you lose, sometimes it rains.”
To win in AM, you must play by the rules and generate an endless stream of statistics. The good news is, just because the data generation process never stops, it does not stop your material, your machines and your parts from being shipped around the world and into all sorts of great applications. Most likely, every time you revise the hardware or software of the machine or improve your material, more tensile bars will be required. The reality is, there will never be enough data — right up until that material or equipment is set to retire. For baseball, like AM data, every day is a new game and a new opportunity to score runs and collect stats.
Author: Michael Hayes
A recent addition to The Barnes Global Advisors, Michael Hayes is the principal ADDvisor on polymer and composites. He previously spent more than 34 years with McDonnell Douglas/Boeing in structural design and additive manufacturing (AM). For the past two decades, he technically and strategically led the evolution of polymer AM from rapid prototyping into aerospace production through the engineering of material and process developments, requirement definitions, application selections, qualifications, testing, certifications, and technology transitions.
